2006 Audio Amp Co – Tweed Deluxe 5E3 – ID 5383

This Audio Amp Co Tweed Deluxe 5E3 from 2006 is an uncompromisingly built boutique amp based on the classic 1957 Fender 5E3 circuit diagram, enhanced with practical features such as line out, bias and fat/tight switches for more tonal variety.
With hand-wired point-to-point turret board construction, MERCURY MAGNETICS® USA transformers and a Celestion Vintage 30 speaker, this amp delivers warm, dynamic tweed tone with enormous headroom and the finest response.
An ideal amplifier for studio, stage or recording - vintage sound with modern flexibility, perfect for players looking for the best of both worlds.

✅ Model: Tweed Deluxe 5E3 (1957 Circuit with improvements)
✅ Power: 15 watts, Class A push/pull
✅ Tube assembly:
- Rectifier: 5Y3GT
- Power Amp: 2×6V6GT
- Driver/PI stage: 12AX7
- 1st Gain/Driver: 12AY7
✅ Bias: cathode bias
✅ Controls: Tone, Bright Volume, Normal Volume
✅ Inputs: 2
Output: 1x speaker output jack
Output impedance: 8 Ω
Speakers: 12″ Celestion Vintage 30
✅ Features:
- Line Out
- Hi Bias / Lo Bias Switch
- Fat/Tight Switch (Input & 2nd Gain Stage)
✅ Structure: Hand-wired, point-to-point on turret board
Chassis: steel
Transformers: MERCURY MAGNETICS® USA
✅ Origin: Audio Amp Co, 2006
✅ Condition: 1st hand
